Honda WH15XTA 98 GPM (1.5") Dewatering High Pressure Water Pump

Model: WH15XK2 | Item Number: 662180
UPC: 786102001670

- 5.00 Stars - Based on 2 Review(s)

Reg. Price: $709.95 $699.00
CARB Compliant Power Equipment

Estimated Ship Date for New Orders: 5/21/2025

Features Technical Specs Reviews Q & A

Features for the Honda WH15XK2

Use this Honda WH15XK2 water pump for multiple applications, including lawn sprinkling. The easy starting OHV Honda Engine provides all the power you need at 118cc. Featuring a Centrifugal pump that is durable enough to withstand pressure as high as 55 PSI. A built in easy carry handle makes this water pump easy to transport too.

Honda OHV Engine: Powerful OHV Honda Commercial Engine GX120 that provides the right amount of power for rugged working conditions.
Pump Style: High Pressure Centrifugal pump built to withstand a maximum pressure of 57PSI and 98 gallons per minute (GPM).
Transportation: Transportation is made simple with the easy carry handle located on top of the water pump.
Pump Applications: Sprinkers, nozzles, irrigation, clear water, slimly, mucky, silt water and fast seepage.

Parts Lookup: Honda WH15X Parts Diagram

WARNING:
This product may contain chemicals known to the State of California to cause cancer, birth defects and other reproductive harm. For more information, go to www.P65Warnings.ca.gov.

Technical Specs for the Honda WH15XK2*

Warranty
Residential Warranty	3 Years
Commercial Warranty	3 Years
Dimensions
Length (in.)	16.3 inches
Width (in.)	14.2 inches
Height (in.)	15.9 inches
Weight (lbs.)	48.5 lbs
Engine Specification
Engine Brand	Honda GX120
Displacement(cc)	118cc
Cylinder Bore	2.4 inches
Cylinder Stroke	1.7 inches
Compression Ratio	8.5:1
Engine Type	4-Cycle
Pump
Pump Style	Dewatering
Pump Type	High Pressure Centrifugal Self-priming
Volute	Rigid Mounted Cast Iron
Impeller	Cast Iron
Mechanical Seal	Carbon/Ceramic
Priming Time	40 sec. at 16.4ft
Gallons Per Minute	98 gal./min.
Inlet Diameter	1.5 inches
Total Head Lift	127 ft.
Suction Head Lift	26 ft.
Maximum Pressure	57 psi
Solids Handling	N/A
Strainer	Part #78325-YB7-020

* These Technical Specs are provided by the manufacturer at the beginning of the model year. Please be aware that the manufacturer may decide to change these specs at any given time without notice.

Reviews for the WH15XK2

Review Rating: Sort By:

by Kevin M
Reviewed on 7/14/2023 - Purchased on 4/13/2023

Review:

No Comments

by Ron S
Reviewed on 8/10/2022 - Purchased on 7/11/2022

Review:

First, Jack's customer service was excellent. Now the Honda WH15XTA. It started on the 1st try and on less than half throttle pumped water up hill through a 100' 11/2" double jacket fire hose a stream of about 40'. I'm more than pleased. I only tested it out the one time because here in California we're in a drought and didn't want to waste my water tank supply.

Q & A for the Honda WH15XK2

Ask us about the Honda WH15XTA 98 GPM (1.5") Dewatering High Pressure Water Pump. Please no repair questions. Your Q&A may be posted to MowersAtJacks.com to help other shoppers, like you, with their purchasing decisions. Thank you.

Add Options for this Equipment for a one time discount now!

Options for the Honda WH15XK2

Add options now for your Honda WH15XK2 at a 1 time discounted price. When you are ready to check out, just click the ADD TO CART button.
More

Check any option you want, and it will automatically update your total below. If there are options that you do not want, just uncheck the box next to it. You will then see your new total.

Equipment: $699.00
Options: $0.00
Total: $699.00

Honda Honda Complete Hose Kit
	Part Number: 124015H1145WHKT Description: This hose kit includes a 20 foot suction hose, a 50 foot discharge hose, a 3/8 inch steel strainer, and nozzle. The style is Male and Female Pin Lug Couplings.	Reg Price: $182.39 $173.27 You Save: 5% Add This Option
