Features for the
California Air Tools 10020CHAD Air Compressor
The CALIFORNIA AIR TOOLS 10020CHAD Ultra Quiet & Oil-Free Air Compressor is designed to be one of the quietest 2.0 Hp air compressors in the industry having only 70 decibels of sound.
The Powerful 2.0 HP motor operates at only 1680 RPM creating less noise and less wear.
The SP Series of Ultra Quiet Air Compressor Motors have been designed to increase duty cycle and allow for longer continuous run times.
The Oil-Free Dual Piston Pump System is engineered for high performance and durability.
The CAT-10020CHAD Air Compressor has an Oil-Free Dual Piston pump designed to have a life cycle before wear of 3000 Plus hours compared to other comparable air compressors with life cycles of 500 hours or less.
The Oil-Free pump allows for use in a variety of temperatures (cold starts) and uneven terrains (no oil in the pump).
The Easy Start Valve feature allows for an easier start up using fewer starting amps.
The Easy Start Valve releases a small amount of air from the pump at start up to produce a no-load condition allowing the motor to spin freely. This no-load start up requires less amps for an easier start up in cold temperatures.
The large low profile 10 Gallon Steel Horizontal Air Tank makes storing under a bench, desk, or shelf very easy.
The factory installed California Air Tools EZ-1 Automatic Drain Valve has been designed to eliminate manually draining your air compressor air tank. The manually set timer allows you to set the time for both the frequency and duration of the draining process.
The 10020CHAD is designed for the person looking for Power, Air Flow, Less Service and Maintenance with at Least 30% Less Noise!
Two pressure control gauges
Easy Start Valve - For Less Starting Amperage
Condor Pressure Switch
Thermal Overload Protector
Less heat which dissipates more efficiently
Comes complete Two Air Filters
Assembled in USA with global components
Commercial Use
One
Industrial 1/4″ female quick connector
Oil-Free Pump
Cleaner air for better tool operation.
Less maintenance and Costs.
Specifications
Sound (Ultra-Quiet): 70 decibels
Maximum Pressure: 125 PSI
Volts: 110v
Hertz: 60hz
Low Amp Draw: 14 Amps
Dedicated Outlet: 15-amp outlet
Gauge: 14-gauge
Cord: 25ft cord
Time to fill tank from empty to full: 120 Seconds
Recovery time from 95 PSI to 125 PSI: 25 Seconds
Duty Cycle: 70/30
Maximum Run Time: 30-60 min. (Depending PSI & CFM)
Tank Size: 10 Gal. (Low Profile) Horizontal Air Tank
Tank Material: Steel
Dimensions: L (19") x W/D (15") x H (26.5")
Weight: 75 lbs..
Horsepower: 2.0 HP (Rated/Running)
Air Flow Per Minute: 6.40 CFM @ 40 PSI
Air Flow Per Minute: 5.30 CFM @ 90 PSI
